POWER STAGE (1 CH.)
2 X EL34/6CA7
INPUT STAGE (1 CH.)
1 X OPAMP JRC4580
DRIVER STAGE (1 CH.)
1 X ECC82/12AU7
INPUT IMPEDANCE
50KOhm
INPUT SENSITIVITY
350 mV for rated power
OUTPUT TAP
6 Ohm
CONFIGURATION
Push-Pull pentode
POWER OUTPUT
25W RMS @ 6Ohm
(1 ch., THD < 1%)
FREQUENCY RESPONSE
from 20Hz to 20KHz +-0.5dB
DISTORSION
1% @ 1KHz (MAX Power)
S/N RATIO
>90dB “A” weighted
INPUTS
3 line (Roma 96DC)
2 line (Roma 96DC+)
1 phono MM
DIGITAL INPUTS (96DC+)
1 USB “B” type Windows/Mac/iOs/Android
1 Toslink Optical
1 Coax S/PDIF
D/A CONVERTER
AK4495SEQ
32bit 768KHz
MAX RESOLUTION (96DC+)
24 bit 192KHz (OPTCoax)
32 bit 384KHz (USB)
DSD up to 5,6MHz (USB)
PC REQUIREMENTS(96DC+)
1GHz processor,512MB RAM, USB 2.0 port
DIMENSIONS (W,D,H)
260x415x200mm
WEIGHT
18Kg
LINE POWER
117 / 230 / 245 Vac, 50/60 Hz (see rear label)
FUSE
See rear label
POWER CONSUMPTION
200W max
REMOTE CONTROL
BODY
Anodized black aluminium
TRANSMISSION TYPE
Infrared
PROTOCOL
RC5
FUNCTIONS
Volume, mute, input selection, st-by
BATTERIES
2 x CR2032
WEIGHT
200g
