CIRCUIT TYPE
Tube/semiconductor
OUTPUT STAGE TYPOLOGY
Class D ICE POWER Module
INPUT STAGE (1 CH.) TUBE
1 x 6922/ECC88
INPUT IMPEDANCE
50KOhm
INPUT SENSITIVITY
200mV for max power
OUTPUT TAP
4-16Ohm
POWER OUTPUT
(1 CH., THD < 1%)
250W (8Ohm)
450W (4Ohm)
FREQUENCY RESPONSE
from 20Hz to 20KHz ± 0.5dB
S/N RATIO
>90 dB “A” weighted
INPUTS
2 line
1 phono
DIGITAL INPUTS
1 USB type “B” Windows/Mac/iOs/Android
1 Toslink Optical
Outputs
D/A CONVERTER
AK4495SEQ
32bit 768KHz
MAX RESOLUTION
24 bit 192KHz (OPT)
32 bit 384KHz (USB)
DSD up to 5,6MHz (USB)
DIMENSIONS (W,D,H)
410x390x95mm
WEIGHT
10Kg
LINE POWER
117 / 230 / 245 Vac,
50/60 HZ (SEE REAR LABEL)
FUSE
See rear label
POWER CONSUMPTION
1000W max
PC REQUIREMENTS
1GHz processor, 512MB RAM, USB 2.0 port
REMOTE CONTROL
BODY
Anodized black aluminium
TRANSMISSION TYPE
Infrared
PROTOCOL
RC5
FUNCTIONS
Volume, mute, input selection, st-by
BATTERIES
2 x CR2032
WEIGHT
200g
