INPUTS
4 x unbalanced (RCA)
1 x balanced (XLR)
INPUT SENSITIVITY
5V RMS Max
INPUT IMPEDANCE
100 kΩ balanced (XLR)
47 kΩ unbalanced (RCA)
TUBES
4 x 6DJ8/ECC88
OUTPUTS
(TRANSFORMER COUPLING)
1 × balanced (XLR)
2 × unbalanced (RCA)
1 × unbalanced REC OUT (RCA)
OUTPUT IMPEDANCE
1 KΩ balanced (XLR)
470Ω unbalanced (RCA)
OUTPUT LEVEL
36 V RMS balanced (XLR)
18 V RMS unbalanced (RCA)
GAIN
+ 22,5 dB balanced (XLR)
+ 16,5 dB unbalanced (RCA)
FREQUENCY RESPONSE
5 – 40 KHz (– 3 dB)
DISTORTION
< 0,1% (20 Hz – 20 kHz @ 1V RMS)
S/N RATIO
> 90 dB “A” weighted
CROSSTALK
> 80dB
LINE POWER
100, 117, 230, 245 Vac +-10%, 50/60 Hz (see rear label)
FUSE
See rear label
CONSUMPTION
60W Max (< 0,5 W St-by)
HEADPHONE OUTPUT
INPUT IMPEDANCE
> 16ohm, high fidelity driver
POWER OUTPUT
>300mW (32ohm)
FREQUENCY RESPONSE
5 – 40 KHz (– 3 dB)
DISTORTION
< 0,1% (20 Hz – 20 kHz)
S/N RATIO
> 95dB, A weight
GAIN
+ 22,5 dB
DIMENSIONS (W,D,H)
410×390×95mm
WEIGHT
10Kg
REMOTE CONTROL
BODY
Anodized black aluminium
TRANSMISSION TYPE
Infrared
PROTOCOL
RC5
FUNCTIONS
Volume, mute, input, selection, st-by
BATTERIES
2 x CR2032
WEIGHT
200g
