Audio Outputs
De-emphasis
±0.1dB referred to main response
Line Outputs Fixed (level)
2.1V RMS at 1kHz
THD + N
<0.007%, 10Hz - 20kHz at full level
Load Impedance
10kΩ (min.)
Output Impedance
10Ω (max.)
Analogue
DIN, RCA
Frequency Response
10Hz – 20kHz, -0.6dB at 20Hz
Formats
CD Formats
Red Book
Disc Compatability
CD, CD-R
Physical
Weight
5.9 kg
Dimensions (HxWxD)
70 x 432 x 301 mm
Power
Power Consumption
9VA (stop mode), 12VA (play mode), 16VA (peak)
Supply Voltage
100V, 115V, 230V; 50 or 60Hz
Supplied with
Supplied with
NARCOM-5 Remote Control, Standard Interconnect, Power-Line Lite mains cable (UK denominations only)
User Control
Front Panel
Four button matrix
Handheld
Remote handset
Remote Control
Infra Red (RC5)
