Display Screen: Immerse yourself with a vibrant 3-inch LCD screen.
Chassis: Crafted from premium Aluminum Alloy for durability and aesthetics.
DAC Audio: Dual ES 9068 DACs deliver unrivaled audio quality.
Audio Processor: Powered by the XMOS XU316 for enhanced performance.
OPA Chip: Equipped with RT 6863 operational amplifiers for precise sound.
Power Supply: High-quality, low-noise switching power supply ensures purity.
Bluetooth Audio Input: Qualcomm QCC5125 module with BT5.0 support.
Bluetooth Protocol Support: SBC/AAC/aptX/aptX LL/aptX HD/LDAC.
USB-B DAC Input: Seamlessly connect to Windows, Mac, Android, and iOS devices.
Formats Supported: Up to stereo DSD512, PCM 768KHz 32Bit, MQA.
USB-C DAC Input: Enjoy high-quality audio from various devices.
Formats Supported: Up to stereo DSD512, PCM 768KHz 32Bit, MQA.
Optical Audio Input: Experience stunning sound through optical connections.
Supported Formats: Up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA.
Coaxial Audio Input: Enhance your audio setup with coaxial input.
Supported Formats: Up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA.
Analog Audio Output: Versatile preamp and headphone outputs.
Preamp: XLR (balanced) + RCA.
Headphone: 6.3mm single-ended.
USB Port: Convenient USB2.0 port for firmware upgrades.
Control Methods: Choose from remote control, mobile app control, or knob control.
Headphone Impedance: Ideal for various headphones (16-300Ω).
Low Gain: 16-32Ω / High Gain: 32-300Ω.
XLR Audio Output: Delivering exceptional performance.
Output Level: 4.1Vrms @ 0dBFS.
THD+N@A-wt: 0.000094% @ 1kHz (-120dB@1kHz).
SNR @ No-wt: 125dB @ 1kHz.
Frequency Response: 20Hz-20kHz (±0.15dB).
RCA Audio Output: Experience balanced sound from RCA output.
Output Level: 2.1Vrms @ 0dBFS.
THD+N@A-wt: 0.000116% @ 1kHz (-118dB@1kHz).
SNR @ No-wt: 121dB @ 1kHz.
Frequency Response: 20Hz-20kHz (±0.15dB).
Headphone (Low Gain Mode): Optimal power and precision.
Output Level: 1.2Vrms @ 0dBFS.
Max Power: 45 mW @ 32Ω.
THD+N@A-wt: 0.00028% @ 1kHz (-111dB@1kHz).
SNR @ No-wt: 114dB @ 1kHz.
Frequency Response: 20Hz-20kHz (±0.15dB).
Headphone (High Gain Mode): Unleash the full potential of high-impedance headphones.
Output Level: 2.8Vrms @ 0dBFS.
Max Power: 26 mW @ 300Ω.
THD+N@A-wt: 0.00014% @ 1kHz (-117dB@1kHz).
SNR @ No-wt: 121dB @ 1kHz.
Frequency Response: 20Hz-20kHz (±0.15dB).
Power Input: Compatible with AC 110~240V 50/60Hz power sources.
Rated Power: Low power consumption at 9W.
Product Dimensions: Compact design at 270mm(W) * 187mm(D) * 50mm(H).
Accessories: Included remote control, power cable, and user manual.
