Driver Type
Rinaro Isodynamic Hybrid Array® MZ4
Operating Principle
Closed
Ear Coupling
Circumaural
Frequency Response
4-92,000 Hz
Impedance
30 Ω
Nominal SPL
100 dB (1 mW / 1 kHz)
Maximum SPL
> 130 dB
Total Harmonic Distortion (THD)
<0.15%
Weight
390 g
MZ4 DRIVER SPECIFICATIONS
Geometrical Shape
Ovoid
Size
92mm x 63mm
Driver Weight
71 g
Casing
Fibreglass reinforced polymer
Diaphragm Type
Rinaro Isoplanar® MZ4
Active Area
3507 mm2
Diaphragm Weight
0.08 g
Acoustic Mass
6.5 kg/m4
Lower Frequency Limit
4 Hz
Upper-Frequency Limit
92,000 Hz
Accessories
Case: Hard EVA pouch with velvet lining
• Two cables included:
- 1.5m soft TPE cable with 3.5mm jack
- 3m soft TPE cable with 3.5mm jack
• Adapters:
- 6.3mm jack adapter
- Airplane jack adapter
• Cables pouch
- Warranty period: 2 years
