Main Column:
System: 4-way sealed box.
Super tweeter: 20mm silk dome with dedicated waveguide, neodymium magnet.
Tweeter: 38mm silk dome with dedicated waveguide, neodymium magnet.
Midrange: 6.5-inch dual-driver motor system with neodymium ring magnet.
Link mid-woofer: 8-inch neodymium slug magnet, Ø 65mm voice coil, sandwich paper cone.
Woofers: 4 x 8-inch dual driver motor system with neodymium ring magnet, Ø 50mm voice coil, sandwich paper cone.
Back emission tw: 28mm silk dome, neodymium magnet.
Back emission md: 4” paper cone driver, neodymium magnet.
Sensitivity: 91dB 1m/2.83V.
Nominal Impedance: 4Ω.
Suggested power output: 100W – 700W.
Dimensions (HxWxD): 1,905 x 650 x 880mm.
Weight: 110 kg per column.
Subwoofer:
System: Sealed box loading, passive subwoofer.
Loudspeakers: Woofers x 2 38cm carbon fiber, sandwich cone.
Frequency response: 16 – 30/80Hz – based on setting of crossover.
Sensitivity: 92dB 1m/2.83V.
Nominal Impedance: 4Ω.
Suggested power output: 500W – 2,000W.
Dimensions (HxWxD): 1,451 x 850 x 525mm.
Weight: 103 kg per column.
Crossover:
System: Full discrete – pure analog stereo/mono active crossover.
Input channels: 2 Unbalanced – 2 Balanced.
Output channels: 8 Unbalanced – 8 Balanced
Frequency response: Main: 25Hz – 150KHz / Proc: 5Hz – 150KHz.
