Audio Inputs
MM Phono Input
via RCA, 47k parallel 470pF input impedance, suitable for 5mV cartridges
Line Level Inputs
130mV sensitivity, 47k input impedance, suitable for 2V
Power Amp In
DIN Socket
Audio Outputs
Powered Accessory Sockets
+24V for Naim phono amplifier
Speaker Outputs
80W per channel into 8 ohms (4mm sockets), 130W per channel into 4 ohms
Line Outputs Variable (level)
Pre-amp (DIN), Bi-amp (DIN), Sub (RCA pair) 775mV, <50 ohms
Line Outputs Fixed (level)
AV (DIN), Stream (DIN) 130mV, 600 ohms
Headphone Output
1/4 inch (6.35mm) TRS Socket
Connectivity
Updates
1 x USB mini-B
Remote Input
1 x 3.5mm jack on rear
Finish
Case
Black powder coated
Front
Brushed and black anodised
Physical
Shipping Weight
17.25 kg
Shipping Dimensions
240 x 590 x 500 mm
Weight
14 kg
Dimensions (HxWxD)
87 x 432 x 314 mm
Power
Power Consumption (max.)
400VA
Mains Supply
115V, 230V; 50 or 60Hz
Power Consumption (quiescent)
37VA
Supplied with
Supplied with
NARCOM-5 Remote Control, Mains Lead, Link Plug and Safety Manual
User Control
Front Panel
Volume control, balance control and front panel buttons
Remote Control
Infra-Red (RC5)
