Power Rating:
1000 watts per channel x 4 @ 4 ohms, all channels driven 610 watts per channel x 4 @ 8 ohms, all channels driven
Peak Power:
1.2 kW peak power from any channel @ 4 Ohm/1kHz with less than 1% distortion
Over Current Protection:
Breaker reset for excessive sustained current
Inputs:
Fully balanced XLR, single-end RCA
Outputs:
Gold plated safety approved five-way binding posts
Damping factor:
750 average, 20Hz to 1kHz
Voltage Gain:
25.8 dB
Dynamic Range:
127dB, A- weighted
Voltage/Current:
98 Vp / 38Ap
Input Sensitivity:
5.0Vp @ 1200W/4 Ohm
Input Impedance:
38 kOhm for both pin 2+ and pin 3-
Channel Separation:
120 dB at 1kHz
Unit Dimensions:
17.5" W x 15.6" D x 5.8" H
Unit Shipping Weight:
38 lbs
Notes:
Highest power output can be obtained using a single 230V, 20A line or dual 120V, 20A lines. A conventional single AC cord is provided.
